p601zero

FPGA computer, software compatible with Pyldin-601

View on GitHub

Pyldin-601 compatible retrocomputer.

History

Overview hardware version 1.2:

board version 1.2

Function Description
CPU System 11 - VHDL 68HC11
FPGA Lattice MachXO2-4000HC module
RAM Builtin FPGA 4KB and/or external static ram 128KB
ROM Builtin FPGA BOOTROM 2KB
Keyboard PS/2
Serial port UART (via keyboard connector)
Video TV (b/w)
Audio AY-3-8912
Storage MMC/SD
Other Onboard SPI and CS ports, 8 bit parallel port (limited to output only)
